Festo MHJ10-S-2,5-QS-6-HF/LP (567798) Solenoid Valve
€7,196.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-567798
Manufacturer Nr.
MHJ10-S-2,5-QS-6-HF/LP
Solenoid Valve
Frequently Bought Together
-
This Item:
€7,196.00Excl. 19% VAT , excl. Shipping Cost
-
Festo MHA1-M1H-3/2G-0,6-TC (197005) Solenoid Valve
€2,819.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VOVG-L12-M52Q-AH-M5-1H2 (560701) Solenoid Valve
€8,403.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 2/2 closed monostable |
| Actuation type | Electrical |
| Build.width [mm] | 10 |
| Normal nominal flow [l/min] | 160 |
| Operating pressure [bar] | 0.5 to 4 |
| Construction set up | Poppet valve without reset spring |
| Reset mode | Pneumatic spring |
| Protection category | IP65 |
| Pitch dimension [mm] | 10,5 |
| Information about operation | Power supply must be able to deliver at least 1.7 A without a voltage breakthrough Do not operate without flow For block assembly with flow max. ambient temperature 45 °C. |
| Sealing principle | Hard |
| installation position | arbitrary |
| Hand assist actuation | none |
| Control type | Direct |
| Flow direction | Not reversible |
| b-value | 0.36 |
| C-value [l/sbar] | 0,66 |
| Max. switching frequency [Hz] | 500 |
| Shifting time on at 4 bar and 24 V in new condition [ms] | 1,0 |
| Shifting time off at 4 bar and 24 V in new condition [ms] | 0,5 |
| Shifting time on at 0.5 bar and 24 V in new condition [ms] | 0,8 |
| Shifting time off at 0.5 bar and 24 V in new condition [ms] | 0,6 |
| Tolerance shifting time off | +15 %/-25 % |
| Tolerance shifting time on | ±15 % |
| Operating voltage range DC [V] | 21.6 to 26.4 |
| Power-on time | 100 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation not possible |
| Limits ambient and media temperature | Depending on the switching frequency |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Bearing temperature [°C] | -20 to 50 |
| Permitted surface temperature magnet [°C] | 120 |
| Medium temperature [°C] | -5 to 60 |
| ambient temperature [°C] | -5 to 60 |
| Product weight [g] | 85 |
| Electrical connection | 3-wire cable |
| Fastening type | pipe installation With throughway bores Selectively: |
| Pneumatic connection 1 | QS-6 |
| Pneumatic connection 2 | QS-6 |
| Material information | RoHs compliant |
| Seals material | HNBR |
| Housing material | PA reinforced PPS reinforced |
| Screws material | Steel |
| KC-mark | KC-EMV |
| CE certificate (see declaration of conformity) | to EU EMC directive |
| Reverse polarity protection | for operating voltage |
| Additional functions | Spark suppression Holding current reduction with energy recovery Protection switch off |
| Eingangswiderstand [kOhm] | 34 |
| Coil characteristic value | 24 V DC: Low current phase 2 W, high current phase 7 W |
| Trigger signal range DC [V] | 3 to 30 |
| Information about incoming current | 0,09 - 0,44 mA bei einem Triggersignal von 3 - 15 V 0,44 - 15,44 mA bei einem Triggersignal von 15 - 30 V Anstieg linear |
| Permitted voltage oscillations | ± 10 % |
| Cable length [MTR] | 2,50 |
| Cable sleeve material | PUR |
| Manufacturer Nr. | MHJ10-S-2,5-QS-6-HF/LP |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568100735 |
| Weight | 0.105000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
