Single-acting NE

Single-acting short-stroke pneumatic cylinders NE are compact pneumatic actuators that extend under compressed air pressure and retract using an internal spring mechanism, designed specifically for applications requiring precise positioning within limited installation space. These cylinders typically feature stroke lengths from 10mm to 50mm with bore diameters ranging from 50mm to 100mm, making them essential components in automated assembly lines, packaging machinery, and semiconductor manufacturing equipment. Industries including automotive component production, medical device assembly, and electronics manufacturing rely on NE series cylinders for clamping, ejecting, and precise positioning operations where consistent repeatability and compact design are critical requirements.

Selection of single-acting NE pneumatic cylinders requires calculating the required force output based on operating pressure typically ranging from 2 to 10 bar, where a 63mm bore diameter cylinder generates approximately 3100N force at 10 bar system pressure. Stroke length selection depends on the actual displacement needed in your application, with available options including 10mm, 20mm, 25mm, 40mm, and 50mm strokes across the NE series product range. The NEM variant offers metric threading connections while standard NE cylinders provide G-thread ports, and proper sizing must account for spring return force reduction which typically decreases available output force by 15-20% compared to double-acting equivalents.

Single-acting short-stroke pneumatic cylinders must comply with ISO 15552 for mounting dimensions and ISO 19973 for pneumatic fluid power cylinders, ensuring interchangeability and safety across international industrial applications. European installations require conformity to EN 983 machinery safety standards and Pressure Equipment Directive 2014/68/EU for pressure vessels, while ATEX certification becomes mandatory for explosive atmosphere applications in chemical and petrochemical facilities. Additional compliance with ISO 4414 pneumatic system safety standards and national workplace safety regulations like OSHA 1910.169 ensures proper integration into automated manufacturing systems while meeting insurance and regulatory requirements.

The primary distinction between NE and NEM single-acting short-stroke cylinders lies in their connection threading and mounting configurations, where NE cylinders feature standard G-thread pneumatic connections while NEM variants utilize metric M-thread ports for enhanced compatibility with European pneumatic systems. Both series offer identical bore diameters from 50mm to 100mm and stroke ranges up to 50mm, but NEM cylinders typically include additional position sensing grooves and magnetic piston options for proximity switch integration. The NEM series also provides enhanced corrosion resistance through improved anodizing treatments and upgraded seal materials, making them preferred choices for food processing and pharmaceutical applications requiring frequent washdown procedures.

NE series single-acting cylinders require clean, dry compressed air filtered to ISO 8573-1 class 7.4.4 with maximum particle size of 40 microns and dew point at least 10°C below minimum operating temperature to prevent internal corrosion and seal degradation. Installation demands rigid mounting using M8 or M10 bolts depending on cylinder bore size, with minimum clearance of 25mm around the cylinder body for maintenance access and proper heat dissipation. System compatibility requires pressure regulation between 2-10 bar with flow control valves sized according to cylinder volume, typically 4mm or 6mm tube connections for bore sizes up to 80mm, while larger cylinders may require 8mm pneumatic tubing to achieve specified cycle times.

Single-acting NE pneumatic cylinders operate within a working pressure range of 2 to 10 bar maximum, with ambient temperature limits from -20°C to +80°C for standard applications, though high-temperature variants can withstand up to +150°C for specialized industrial processes. Standard cylinders meet IP54 protection rating against dust ingress and water splashing, while sealed variants achieve IP65 rating suitable for food processing and outdoor applications requiring washdown capability. The maximum permissible pressure of 16 bar provides adequate safety margin according to EN 983 standards, and operating media must be compressed air or inert gases with maximum humidity content of 50% relative humidity at 20°C to prevent internal condensation and seal deterioration.

Single-acting short-stroke pneumatic cylinders require preventive maintenance every 2 million operating cycles or annually, whichever occurs first, including inspection of rod seals, wiper seals, and internal spring tension to maintain specified force output and prevent air leakage. Expected service life ranges from 5 to 10 million cycles depending on operating pressure, cycle frequency, and environmental conditions, with proper filtration and lubrication extending operational lifespan significantly. Critical inspection points include measuring internal leakage rates which should not exceed 10 ml/min at rated pressure, checking rod straightness within 0.1mm tolerance, and verifying spring return force maintains at least 85% of original specification to ensure reliable retraction performance throughout the cylinder's operational life.
