Festo DSNU-25-125-PPS-A (559287) Standards-Based Cylin

Name: Festo DSNU-25-125-PPS-A (559287) Standards-Based Cylin
Brand: Festo
SKU: FES-559287
Price: 532 EUR
Availability: InStock

€532.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-559287

Manufacturer Nr.

DSNU-25-125-PPS-A

Standards-Based Cylin

The product may differ from the illustration

Frequently Bought Together

This Item: Festo DSNU-25-125-PPS-A (559287) Standards-Based Cylin
€532.00
Excl. 19% VAT , excl. Shipping Cost
Festo ESNU-32-25-P-A (196377) Round Cylinder
€6,086.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSNU-50-25-PPV-A (196040) Round Cylinder
€8,834.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke [mm]	125
Piston diameter	25 mm
Piston rod thread	M10x1,25
Dampening	PPS: Self-setting pneumatic end position dampening
installation position	arbitrary
Complies to standard	CETOP RP 52 P ISO 6432
Piston rod end	Male thread
Construction set up	Piston piston rod cylinder tube
Position detection	For proximity switch
Variants	One-sided piston rod
Operating pressure [bar]	1 to 10
Principle of operation	double acting
Maritime classification	see Certificate
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	2 - moderate corrosion stress
ambient temperature [°C]	-20 to 80
Impact energy at the end positions [J]	0,30
Theoretical force at 6 bar, Return flow [N]	247,4
Base weight at 0 mm stroke [g]	238,0
Supplement moved mass per 10 mm stroke [g]	6
Fastening type	With Accessories
Pneumatic connection	G1/8
Material information	RoHs compliant
Cover material	Aluminium wrought alloy No-colour anodised
Seals material	NBR TPE-U(PU)
Piston rod material	High-alloyed stainless steels
Cylinder tube material	High-alloyed stainless steels
Theoretical force at 6 bar, flow [N]	294,5
Moving mass at 0 mm stroke [g]	71,0
Weight supplement per 10 mm stroke [g]	11,0
Dampening length [mm]	17

More Information
Manufacturer Nr.	DSNU-25-125-PPS-A
Manufacturer	Festo
EAN	4052568205638
Weight	0.360000
HS-Code	84123100
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
