Festo pneumatic cylinder for precise linear motion and defined force in automation.
Standards-Based Cylin DSNU-25-200-PPS-A - Festo 559289
FESTO
Original product
Net price (excl. VAT)
€59.88
Excl. 19% VAT ,
excl. Shipping Cost
Available
Fast shipping
Item
FES-559289
Manufacturer no.
DSNU-25-200-PPS-A
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.DSNU-25-200-PPS-A
EAN4052568205652
Customs tariff number84123100
ConditionNew
Article
FES-559289
Frequently Bought Together
-
This Item:
€59.88Excl. 19% VAT , excl. Shipping Cost
-
Round Cylinder ESNU-40-10-P-A - Festo 196379
€78.33Excl. 19% VAT , excl. Shipping Cost
-
Standards-Based Cylind DSNU-16-50-PPV-A - Festo 19230
€49.04Excl. 19% VAT , excl. Shipping Cost
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Stroke [mm] | 200 |
| Piston diameter | 25 mm |
| Piston rod thread | M10x1,25 |
| Dampening | PPS: Self-setting pneumatic end position dampening |
| installation position | arbitrary |
| Complies to standard | CETOP RP 52 P<br>ISO 6432 |
| Piston rod end | Male thread |
| Construction set up | Piston<br>piston rod<br>cylinder tube |
| Position detection | For proximity switch |
| Variants | One-sided piston rod |
| Operating pressure [bar] | 1 to 10 |
| Principle of operation | double acting |
| Maritime classification | see Certificate |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Impact energy at the end positions [J] | 0,30 |
| Theoretical force at 6 bar, Return flow [N] | 247,4 |
| Base weight at 0 mm stroke [g] | 238,0 |
| Supplement moved mass per 10 mm stroke [g] | 6 |
| Fastening type | With Accessories |
| Pneumatic connection | G1/8 |
| Material information | RoHs compliant |
| Cover material | Aluminium wrought alloy<br>No-colour anodised |
| Seals material | NBR<br>TPE-U(PU) |
| Piston rod material | High-alloyed stainless steels |
| Cylinder tube material | High-alloyed stainless steels |
| Theoretical force at 6 bar, flow [N] | 294,5 |
| Moving mass at 0 mm stroke [g] | 71,0 |
| Weight supplement per 10 mm stroke [g] | 11,0 |
| Dampening length [mm] | 17 |
| Manufacturer Nr. | DSNU-25-200-PPS-A |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568205652 |
| Weight | 0.238000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Bohrung (mm) | 25.000000 |
| Betriebsdruck max [bar] | 10.000000 |
| Hub [mm] | 200.000000 |
| Pneumatischer Anschluss | G1/8 |
