Festo pneumatic cylinder for precise linear motion and defined force in automation.
Round Cylinder DSNU-63-40-P-A - Festo 196011
FESTO Original product
Net price (excl. VAT)
€107.73
Item FES-196011
Manufacturer no. DSNU-63-40-P-A
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.DSNU-63-40-P-A
EAN4052568158620
Customs tariff number84123100
ConditionNew
Article
FES-196011
Frequently Bought Together
- This Item: €107.73
- Round Cylinder ESNU-50-50-P-A - Festo 196384 €96.09
- Standards-Based Cylind DSNU-20-40-PPV-A - Festo 19236 €56.12
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Stroke [mm] | 40 |
| Piston diameter | 63 mm |
| Piston rod thread | M16x1,5 |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Construction set up | Piston<br>piston rod<br>cylinder tube |
| Position detection | For proximity switch |
| Operating pressure [bar] | 1 to 10 |
| Principle of operation | double acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Theoretical force at 6 bar, Return flow [N] | 1.681,9 |
| Fastening type | With Accessories |
| Pneumatic connection | G3/8 |
| Material information | RoHs compliant |
| Cover material | Aluminium wrought alloy |
| Seals material | NBR<br>TPE-U(PU) |
| Piston rod material | High-alloyed steel |
| Cylinder tube material | High-alloyed stainless steels |
| Theoretical force at 6 bar, flow [N] | 1.870,3 |
| Moving mass [g] | 559 |
| Product weight [g] | 1.621 |
| Manufacturer Nr. | DSNU-63-40-P-A |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568158620 |
| Weight | 1.600000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Bohrung (mm) | 63.000000 |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatischer Anschluss | G3/8 |
| Hub [mm] | 40.000000 |
