Festo DSNU-63-80-P-A (196013) Round Cylinder

Name: Festo DSNU-63-80-P-A (196013) Round Cylinder
Brand: Festo
SKU: FES-196013
Price: 9735 EUR
Availability: InStock

€9,735.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-196013

Manufacturer Nr.

DSNU-63-80-P-A

Round Cylinder

The product may differ from the illustration

Frequently Bought Together

This Item: Festo DSNU-63-80-P-A (196013) Round Cylinder
€9,735.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSNU-25-20-P-A (1908306) Standards-Based Cyli
€4,474.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSNU-25-50-PPV-A (19246) Standards-Based Cylind
€5,312.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke [mm]	80
Piston diameter	63 mm
Piston rod thread	M16x1,5
Dampening	P: Elastic silencer rings / plates double-sided
installation position	arbitrary
Construction set up	Piston piston rod cylinder tube
Position detection	For proximity switch
Operating pressure [bar]	1 to 10
Principle of operation	double acting
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	2 - moderate corrosion stress
ambient temperature [°C]	-20 to 80
Theoretical force at 6 bar, Return flow [N]	1.681,9
Fastening type	With Accessories
Pneumatic connection	G3/8
Material information	RoHs compliant
Cover material	Aluminium wrought alloy
Seals material	NBR TPE-U(PU)
Piston rod material	High-alloyed steel
Cylinder tube material	High-alloyed stainless steels
Theoretical force at 6 bar, flow [N]	1.870,3
Moving mass [g]	659
Product weight [g]	1.797

More Information
Manufacturer Nr.	DSNU-63-80-P-A
Manufacturer	Festo
EAN	4052568158644
Weight	1.800000
HS-Code	84123100
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
