Festo DSNU-63-50-PPV-A (196052) Round Cylinder

Name: Festo DSNU-63-50-PPV-A (196052) Round Cylinder
Brand: Festo
SKU: FES-196052
Price: 10614 EUR
Availability: InStock

€10,614.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-196052

Manufacturer Nr.

DSNU-63-50-PPV-A

Round Cylinder

The product may differ from the illustration

Frequently Bought Together

This Item: Festo DSNU-63-50-PPV-A (196052) Round Cylinder
€10,614.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSNU-50-80-PPS-A (559318) Round Cylinder
€8,962.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSNU-63-320-PPS-A (559334) Round Cylinder
€12,125.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke [mm]	50
Piston diameter	63 mm
Piston rod thread	M16x1,5
Dampening	PPV: Pneumatic dampening both sides adjustable
installation position	arbitrary
Construction set up	Piston piston rod cylinder tube
Position detection	For proximity switch
Operating pressure [bar]	1 to 10
Principle of operation	double acting
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	2 - moderate corrosion stress
ambient temperature [°C]	-20 to 80
Theoretical force at 6 bar, Return flow [N]	1.681,9
Fastening type	With Accessories
Pneumatic connection	G3/8
Material information	RoHs compliant
Cover material	Aluminium wrought alloy
Seals material	NBR TPE-U(PU)
Piston rod material	High-alloyed steel
Cylinder tube material	High-alloyed stainless steels
Theoretical force at 6 bar, flow [N]	1.870,3
Dampening length [mm]	21
Moving mass [g]	584
Product weight [g]	1.665

More Information
Manufacturer Nr.	DSNU-63-50-PPV-A
Manufacturer	Festo
EAN	4052568159009
Weight	1.600000
HS-Code	84123100
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
