Festo HPV-14-40-A (529352) Feed Separator

Festo
€69,519.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-529352

Manufacturer Nr.
HPV-14-40-A
Feed Separator
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Stroke [mm] 40
Piston diameter 14 mm
Max. exchange precision [mm] 0,3
Max. tappet play Sx [mm] 0,05
Max. tappet play Sz [mm] 0,03
Max. gripper jaw play ax [deg] 0,07
Max. gripper jaw play ay [deg] 0,12
Max. gripper jaw play az [deg] 0,175
Fastening external finger throughway bores
Dampening No dampening
installation position arbitrary
Principle of operation double acting
Construction set up Double piston
piston rod
Blocking pusher
non-rotating
Position detection For proximity switch
Half cycle [ms] 234,2
Anti-twist lock / guide Square guide
Cycle time [ms] 468,4
Operating pressure [bar] 3 to 8
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 - moderate corrosion stress
ambient temperature [°C] 5 to 60
Max. force on the finger Fz static [N] 100
Max. torque on finger Mr static [Nm] 5
Max. torque on finger Mx static [Nm] 5
Max. torque on finger My static [Nm] 5
Theoretical force at 6 bar, Return flow [N] 75
Theoretical force at 6 bar, flow [N] 90
Max. mass per external griper finger [g] 150
Product weight [g] 460
Alternative connections M5
Fastening type Selectively:
Female thread and centring sleeve
With Throughway bore and centring sleeve
Pneumatic connection M5
Material information Copper and PTFE-free
More Information
Manufacturer Nr. HPV-14-40-A
Manufacturer Festo
EAN 4052568163945
Weight 0.500000
HS-Code 84798997
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
