Festo pneumatic cylinder for precise linear motion and defined force in automation.
Stopper Cylinder DFSP-Q-50-25-PR-PA - Festo 576166
FESTO Original product
Net price (excl. VAT)
€199.94
Item FES-576166
Manufacturer no. DFSP-Q-50-25-PR-PA
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.DFSP-Q-50-25-PR-PA
EAN4052568225308
Customs tariff number84123100
ConditionNew
Article
FES-576166
Frequently Bought Together
- This Item: €199.94
- Stopper Cylinder DFSP-32-25-DS-PA - Festo 576101 €110.73
- Stopper Cylinder DFSP-32-25-PS-PA - Festo 576104 €110.73
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Stroke [mm] | 25 |
| Piston diameter | 50 mm |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Principle of operation | single action<br>Pulling |
| Construction set up | Piston<br>Piston rod with roller<br>profile tube<br>non-rotating |
| Position detection | For proximity switch |
| Anti-twist lock / guide | Flattened piston rod |
| Operating pressure [bar] | 1.2 to 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -10 to 80 |
| Impact strength [N] | 5.000 |
| Permitted shear force during switching process [N] | 1.250 |
| Max. cycle frequency [Hz] | 5 |
| Fastening type | With throughway bores<br>With female thread<br>With Accessories<br>Selectively: |
| Pneumatic connection | G1/8 |
| Material information | RoHs compliant |
| Flush screw material | Zinc plated steel |
| Cover material | Aluminium wrought alloy<br>anodized |
| Seals material | TPE-U(PU) |
| Piston rod material | High-alloyed stainless steels |
| Roller material | Zinc plated steel |
| Cylinder tube material | Aluminium wrought alloy<br>Smooth anodised |
| Variants | non-rotating piston rod |
| Manufacturer Nr. | DFSP-Q-50-25-PR-PA |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568225308 |
| Weight | 1.300000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Bohrung (mm) | 50.000000 |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatischer Anschluss | G1/8 |
| Hub [mm] | 25.000000 |
