Flat dual footplate with gate connection for turnstile - Iteco 9266102

At a turnstile the operator has to stand exactly where the measurement takes place. The flat dual footplate 9266.102 provides two separate contact pads for that purpose and is wired to the access gate, so the test station rates the left and the right foot individually before the tripod is unlocked.

Operating features

• Two separate contact pads - each foot is measured on its own, so one faulty shoe does not pass unnoticed.
• Connection to the gate - the plate is built to be wired to the turnstile access gate rather than to a wall station.
• Flat design - the platform lies on the floor in front of the turnstile and brings the operator into the correct measuring position.
• Made for high traffic - the tread surface is sized for daily shift changes in an industrial plant.

Technical data

Applications

Entry locks to EPA areas where the footwear test of every person is recorded and the passage is released only afterwards. Separate testing of both feet is required wherever a single dissipative shoe is not accepted as proof.

Compatibility and scope of supply

The plate belongs to the turnstile access gate 9266.100 and works with the Iteco test station mounted there. For wall mounted or stand up test stations Iteco lists the separate dual footplate 9264.965, which is not intended for the gate. Supplied as one footplate, while the test station and the turnstile are ordered separately.

Standards and origin

Testing both feet separately follows the personnel test to IEC 61340-5-1. Made in Italy.
