ESD MIX SMD cabinet 340/22, 4 drawers, SMD Box 01 to 04, black - Licefa 8900047

On repair and prototyping benches, 0402 resistors sit next to ICs and connectors. This MIX cabinet covers that range in a single unit: four drawers, each with a block of a different box size, totalling 268 SMD boxes from 16 x 12 x 15 mm to 68 x 57 x 15 mm inside. Body, drawers and boxes are black and made of PS with a surface resistance of 10⁴ to 10¹¹ Ω.

Benefits

• Four box sizes in one cabinet: from 16 x 12 x 15 mm for tiny chips to 68 x 57 x 15 mm for larger parts
• One drawer per box size, so the size is obvious as soon as the drawer opens
• Uniform black PS, surface resistance 10⁴ to 10¹¹ Ω, for EPAs to DIN EN 61340-5-1
• Four drawers of 340 x 250 x 22 mm each on a 352 x 265 mm footprint, 141 mm high
• Supplied assembled and filled, made in Germany

Applications

• Repair and service with changing components
• Laboratory, prototyping and small batches
• SMD assembly with a mixed component range
• Storage of sensitive components at the EPA workstation
