8100 SA 9 Zyklop Speed ratchet set, 1/4" drive, imperial, 28 pieces - Wera 05004019001
Imperial 1/4" ratchet set with the Zyklop Speed ratchet: freely pivoting head with 5 locking positions, 72 teeth and a 5° return angle. Plus nine sockets from 3/16" to 1/2", three extensions and 15 bits in a light textile box.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For imperial screws in changing installation positions, a ratchet that adapts to the space helps. The 8100 SA 9 contains the Zyklop Speed ratchet with freely pivoting head and fast-turning function, plus nine sockets from 3/16" to 1/2" and 15 bits in a 205 x 110 x 60 mm textile box.
Benefits
- Zyklop 6 in 1: fine-tooth ratchet, pivoting ratchet, angled ratchet, ratchet with safety lock, power ratchet and screwdriver.
- Freely pivoting ratchet head, lockable by slide switch at 0°, 15° and 90° to the left and right.
- Fast mover: flywheel design, Kraftform handle and free-turning sleeve speed up screwdriving.
- 72 teeth for a return angle of only 5°, reversing via knurled wheel in any position.
- Take it easy tool finder and a textile box that can be stored upright on the shelf and protects surfaces.
Applications
Assembly and service on machines, vehicles and equipment with imperial screws, especially in tight or hard-to-reach installation positions and for mobile use.
Technical data
| Drive | 1/4" |
|---|---|
| Ratchet | 1 x 8000 A Zyklop Speed ratchet, 152 mm |
| Sockets | 9 x 8790 HMA Zyklop socket: 3/16", 7/32", 1/4", 9/32", 5/16", 11/32", 3/8", 7/16", 1/2", each 23 mm long |
| Extensions | 1 x 8794 LA extension with free-turning sleeve 150 mm, 1 x 8794 A Wobble extension 56 mm, 1 x 8784 A1 connecting part 37 mm |
| Bits | PH 1, PH 2, PH 3, PZ 1, PZ 2, TX 10, TX 15, TX 20, TX 25, TX 27, TX 30, hexagon socket 5/32", 3/16", 7/32", 1/4", each 50 mm long |
| Accessory | Hook and loop fastener strip 120, 120 x 50 mm |
| Size | 205 x 110 x 60 mm |
| Weight | 842 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 05004019001 |
| EAN | 4013288173843 |
| HS-Code | 82041200 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Czechia |
| Height | 60 mm |
| Width | 110 mm |
