Kraftform Kompakt VDE Big Pack 1, VDE interchangeable blade set with 2 handles and 24 blades, 26 pieces - Wera 05006617001
Comprehensive VDE set with 2 x 817 VDE handles and 24 interchangeable 157 mm blades, mostly with reduced blade diameter, for PH, PZ, PH/S, PZ/S, TORX TX 8 to TX 30, 64 i and slotted. Individually tested to IEC 60900 at 10,000 V for safe work up to 1,000 V.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Kraftform Kompakt VDE Big Pack 1 is the set for users who have to expect many different profiles on live equipment: 24 insulated blades from TORX TX 8 to TX 30 through PH, PZ and both PlusMinus variants to slotted 1.2 x 6.5 mm, plus two handles. Most blades have a reduced blade diameter (iS) for low-lying screws.
Benefits
- Most blades with reduced blade diameter: low-lying screw and spring elements can be reached
- 2 VDE-insulated Kraftform 817 VDE handles with anti-roll protection
- Kraftform Plus handle: hard zones for high working speed, soft zones for high torque transfer, prevents blisters and calluses
- Take it easy tool finder: colour coding by profile and laser-engraved size indication
- Spinning function and anti-roll protection on the blades
- Folding pouch, compatible with Wera 2go
Applications
Electrical installation, panel and plant building, maintenance and service with changing screw profiles.
Standards and safety
The tools are individually tested at 10,000 V in accordance with IEC 60900, ensuring safe working at the approved voltage of 1,000 V.
Technical data
| Set contents | 26 pieces |
|---|---|
| Handles | 2 x 817 VDE Kraftform, 9 x 98 mm |
| Phillips (62 iS) | PH 1, PH 2 x 157 mm |
| Pozidriv (65 iS) | PZ 1, PZ 2 x 157 mm |
| PlusMinus PH/S (62 iS) | # 1, # 2 x 157 mm |
| PlusMinus PZ/S (65 iS) | # 1, # 2 x 157 mm |
| TORX (67 i) | TX 8, TX 9, TX 10, TX 30 x 157 mm |
| TORX (67 iS) | TX 15, TX 20, TX 25 x 157 mm |
| 64 i | 2.5 / 3 / 4 / 5 x 157 mm |
| Slotted (60 i) | 0.4 x 2.5 / 1.2 x 6.5 x 157 mm |
| Slotted (60 iS) | 0.6 x 3.5 / 0.8 x 4 / 1 x 5.5 x 157 mm |
| Size | 200 x 110 x 85 mm |
| Weight | 855 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 05006617001 |
| EAN | 4013288229557 |
| HS-Code | 82054000 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Czechia |
| Height | 85 mm |
| Width | 110 mm |
| Norm | DIN EN IEC 60900 |
| Certification | IEC 60900 |
