Kraftform Kompakt 60 Imperial bits assortment, 17 pieces, 89 mm bits with 816 R holder - Wera 05051042001
Pouch with 16 bits in 89 mm length for PH, TORX, slotted, imperial hexagon socket and square screws. Includes the 816 R holder with Rapidaptor quick-release chuck and Kraftform Plus handle for manual and power tool use.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Anyone servicing joints with imperial hexagon socket and square (Robertson) screws needs the right profiles in one pouch. The Kraftform Kompakt 60 Imperial combines 16 bits in 89 mm length with a Kraftform holder that works by hand as well as in a power tool.
Benefits
- 89 mm long bits also reach deeper screws.
- 816 R holder with Rapidaptor quick-release chuck: push the bit in and it locks automatically when applied to the screw.
- Kraftform Plus handle: hard zones for high working speeds, soft zones for high torque transfer.
- Tough bits for universal use.
- Sturdy pouch for fixed workplaces and external sites.
Applications
Assembly and service on equipment with imperial fasteners, electrical and furniture work with square screws, workshop and mobile use by hand or with a cordless screwdriver.
Standards and safety
The Rapidaptor quick-release chuck holds 1/4" bits as per DIN ISO 1173-C 6.3 and E 6.3 as well as Wera series 1 and 4.
Technical data
| Set contents | 17 pieces plus hook and loop strip |
|---|---|
| Holder | 1 x 816 R Rapidaptor, 1/4" x 119 mm |
| Phillips bits 851/4 Z | PH 1, PH 2, PH 3 x 89 mm |
| TORX BO bits 867/4 Z | TX 10, TX 15, TX 20, TX 25, TX 30 x 89 mm |
| Slotted bit 800/4 Z | 1 x 5.5 x 89 mm |
| Hexagon socket bits 840/4 Z | 3/32", 1/8", 5/32", 3/16" x 89 mm |
| Square bits 868/4 | #1, #2, #3 x 89 mm |
| Bit drive | 1/4" as per DIN ISO 1173-C 6.3 and E 6.3, Wera series 1 and 4 |
| Size | 155 x 130 x 55 mm |
| Weight | 520 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 05051042001 |
| EAN | 4013288156037 |
| HS-Code | 82079030 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Czechia |
| Height | 55 mm |
| Width | 130 mm |
| Norm | ISO 1173 |
