Kraftform Kompakt 838 RA-R M Set 1 ratchet screwdriver set 1/4", 15 pieces, 89 mm bits - Wera 05051061001
Bitholding screwdriver with Rapidaptor quick-release chuck and ratchet integrated in the handle (36 teeth, 10° return angle) plus 14 bits in 89 mm length for PH, PZ, TORX, hexagon socket and slotted screws. In a pouch compatible with Wera 2go.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Screwdriving without tedious repositioning: the ratchet integrated in the handle of the 838 RA-R M works with 36 teeth and a 10° return angle. The 89 mm long bits also reach deeper screws, and the Rapidaptor quick-release chuck changes them in seconds.
Benefits
- Fine-toothed ratchet mechanism fully embedded in the handle, "spinning" possible.
- Ergonomic, intuitive switching to clockwise, counterclockwise or position 0.
- Rapidaptor holder for fast bit changes.
- Multi-component Kraftform Plus handle for fast, ergonomic screwdriving without blisters and calluses.
- Sturdy pouch compatible with Wera 2go.
Applications
Assembly and service with many repetitive screw connections, deeper screws in equipment and housings, mobile use with the Wera 2go system.
Standards and safety
The bit mounting is designed for bits with 1/4" hexagon drive as per DIN ISO 1173-C 6.3 and E 6.3.
Technical data
| Set contents | 15 pieces plus hook and loop strip |
|---|---|
| Bitholding screwdriver | 1 x 838 RA-R M with ratchet function, 1/4" x 123.5 mm |
| Ratchet | 36 teeth, 10° return angle |
| Phillips bits | PH 1, PH 2, PH 3 x 89 mm |
| Pozidriv bits | PZ 1, PZ 2, PZ 3 x 89 mm |
| TORX bits 867/4 Z | TX 10, TX 15, TX 20, TX 25 x 89 mm |
| Hexagon socket bits 840/4 Z | 3, 4, 5 mm x 89 mm |
| Slotted bit 800/4 Z | 1 x 5.5 x 89 mm |
| Bit drive | 1/4" as per DIN ISO 1173-C 6.3 and E 6.3, Wera series 1 and 4 |
| Size | 160 x 110 x 55 mm |
| Weight | 477 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 05051061001 |
| EAN | 4013288229779 |
| HS-Code | 82079030 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Czechia |
| Height | 55 mm |
| Width | 110 mm |
| Norm | ISO 1173 |
