ESD Strapping Band PP-ESD Black, 8 mm Wide, 750 m Roll - A1-ESD EP0709011

Strapping ESD containers and cartons with ordinary plastic band introduces, at the very end of the packing line, exactly the material that can undo the protective measures taken before it. This band is made from polypropylene in dissipative PP-ESD grade and reaches a surface resistance below 1.0 x 10E7 ohm. The narrow 8 mm version comes on a 750 m roll and is the variant for smaller strapping heads and lighter packages.

Benefits

• Surface resistance below 1.0 x 10E7 ohm, the band stays dissipative and builds no charge as it is pulled off the roll.
• Band width 8 mm, the narrow version of the range for smaller packages and tools rated accordingly.
• Roll length 750 m, one roll covers a long packing shift and needs changing only rarely.
• Thickness 0.4 mm, the band tensions and welds cleanly without adding much bulk.
• PP-ESD polypropylene, light, tear resistant and processed without residue.
• Suitable for hand tools and automatic strapping machines, the same roll serves both working methods.
• Black colour, ESD packaging material remains distinguishable from ordinary band at goods issue.

Technical data

Application

The band is used at goods issue and in internal logistics wherever containers, lids or cartons holding electronic assemblies are secured. Typical jobs are lashing stacked ESD containers on a pallet, securing carton lids before dispatch and bundling cut sheets in the store. Because strapping is the last step and often happens outside the EPA, a dissipative band is the simplest way to keep the protection chain intact up to shipment.

Note on the range

The strapping band is stocked in several band widths. This article is the 8 mm wide version.
