Conductive drawer insert with 25 compartments, Liastat, 10E3 to 10E8 ohm

Storing small parts loose in a drawer costs search time and, inside an EPA, adds the risk of components being charged by an insulating container. This thermoformed insert divides the drawer into 25 compartments and is made from Liastat with a surface resistance of 10E3 to 10E8 ohm, a material that drains charge instead of holding it. The inner height is 32 mm.

Benefits

• Surface resistance of 10E3 to 10E8 ohm, so the insert dissipates charge in a controlled way and can be used inside the ESD protected area.
• 25 compartments per insert keep part types and values apart and ready to grab without repacking.
• Inner height of 32 mm, enough for tape sections, connectors, screws and single small assemblies.
• Thermoformed in one piece, with no joints for swarf and small parts to get caught in.
• Black throughout, so labels and light coloured components stand out clearly in the compartment.
• Supplied as a single piece, letting drawers be equipped one at a time as needed.

Application

The insert equips drawer cabinets and workbench drawers in electronics manufacturing, in repair work and in small parts stores. Typical contents are tape sections, connectors, semiconductors in tubes, screws and assembly hardware that has to stay within reach at the workstation without getting mixed up. Because the material drains charge, the drawer stays part of the grounded environment and does not have to be kept out of the EPA as insulating foreign material. The range also covers inserts with 6 and with 12 compartments.
