ESD Personnel Tester EPA-RESIST ICS with Interface to Time Recording Systems

The EPA-RESIST ICS checks the wrist strap and footwear of personnel at the EPA entrance. Through its Interface Communication System it exchanges data with an existing time recording or access control system, so only one database and one ID card per employee has to be managed.

Benefits

• Additional serial interface for data exchange with time recording or access control
• Only one database to manage and one ID card per employee
• Special test function (passive voltage measurement) for pregnant staff and people with electronic implants such as pacemakers or hearing implants
• Access control via three freely configurable relays

Technical data

• Test: wrist strap and footwear, automatic shoe-to-shoe test
• Foot electrode: with or without shoe scraper
• Display: 7 inch colour touchscreen
• Measurement: temperature and relative humidity
• Processor: 32 bit
• Test voltage selectable: 33 V, 50 V or 100 V
• Limits freely adjustable, test assignment per employee
• Menu language: German or English
• Interface: additional serial interface (ICS)

Scope of delivery

EPA-RESIST ICS, foot electrode (model selection), mounting console for wall or desk, 24 V power supply with cable, relay output connection cable, operating manual, calibration certificate.

Standards

Personnel grounding test per IEC 61340-5-1.
