Aluminium elevator tripod 84 to 246 cm with circular bubble - Leica CET103

Recording heights and axes with a Leica DISTO all day long, most time is lost moving and levelling the tripod. With its crank column the CET103 covers 84 cm to 246 cm, so floor level and ceiling level work are handled from the same setup.

Benefits

• Crank adjustment of the centre column, the height changes under load in a controlled way without slipping.
• Working range from 84 cm to 246 cm including the extension tube, one tripod for floor pick-ups and readings close to the ceiling.
• Millimetre scale on the column, a set instrument height is restored exactly later on.
• Built-in circular bubble, rough levelling needs no extra instrument.
• Fast clamps on the legs, setup and take-down take only a few moves.
• Exchangeable rubber feet, wear on screed and concrete is fixed without replacing the tripod.
• Aluminium build at 5.7 kg, portable and still stable enough for continuous professional use.

Technical data

Applications

Room surveys and as-built documentation during fit-out, transferring heights in shell construction, setting up Leica DISTO meters and 3D DISTO systems, and check measurements where the same instrument height has to be reached repeatedly.

Compatibility and scope of delivery

The CET103 is a multifunctional tripod from the Leica DISTO and 3D DISTO accessory range. Delivery covers the tripod with crank column, extension tube, circular bubble and shoulder strap. Instrument and tripod adapter are not included and are ordered separately.

Origin and customs data

Country of origin Hungary, customs tariff number 9620001000, EAN 7640110692172. No battery included.
