These Ultra Fine SMD tweezers use a 0.2 mm tip bent at 40 degrees in a sickle shape to pick up even the smallest components safely under a microscope. Made from antimagnetic stainless steel with a matt, glare-free surface, the 120 mm tweezers of form 7a also suit robotic pick-and-place work.
SMD Tweezers Ultra Fine 120 mm Form 7a, 40 Degree Bend, 0.2 mm Tip, Antimagnetic Stainless Steel - Bernstein 5-055-UF
BERNSTEIN Original product
Net price (excl. VAT)
€16.64
Item BS-5-055-UF
Manufacturer no. 5-055-UF
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.5-055-UF
EAN4250838516471
Customs tariff number82032000
ConditionNew
Article
BS-5-055-UF
Frequently Bought Together
Placing and reworking the finest SMD components under a microscope depends on tip geometry. The Ultra Fine SMD tweezers 5-055-UF feature a 40 degree sickle-shaped bend tapering to a 0.2 mm tip with a tolerance of +/-0.05 mm for maximum precision.
Benefits
- A 0.2 mm fine tip with +/-0.05 mm tolerance reliably grips the smallest SMD components.
- The 40 degree sickle-shaped bend, approximately 35 mm long, allows sideways access under the microscope.
- Antimagnetic SA stainless steel does not detune sensitive components or assemblies.
- The matt polished, glare-free surface reduces reflections while working under the microscope.
- Repeatable tip tolerance also suits robotic pick-and-place applications.
Technical Data
| Feature | Value |
|---|---|
| Form | 7a |
| Tip geometry | 40 degree sickle-shaped bend, very sharply pointed, approx. 35 mm |
| Tip thickness | 0.2 mm (+/-0.05 mm tolerance) |
| Material | Stainless steel SA, antimagnetic |
| Surface | Matt polished, smooth and glare-free |
| Overall length | 120 mm |
| Weight | 15 g |
Application
- Precise gripping, holding, and positioning of SMD components in laboratories and on test equipment under the microscope.
- Equipping robotics for pick-and-place work thanks to the repeatable 0.2 mm tip tolerance.
- Placement and rework in electronics manufacturing.
Standards and Delivery Data
- EAN 4250838516471
- Customs tariff number 82032000
- Country of origin Italy
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 5-055-UF |
| Manufacturer | Bernstein |
| EAN | 4250838516471 |
| Weight | 0.015000 |
| Colour | Stainless Steel |
| HS-Code | 82032000 |
| GPSR manufacturer information | BERNSTEIN Werkzeugfabrik Industriehof Trecknase 1 DE-42897 Remscheid www.bernstein-werkzeuge.de |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
