The ESD SMD tweezers 5-864-135 feature a flat, upward-bent tip 5.4 mm wide with a slip-resistant, dip-insulated ESD coating and a surface resistance of 10^6 to 10^9 ohms. They are designed for handling SMD components and sensitive optical parts such as lenses and mirrors.
ESD SMD Tweezers 105 mm Form 46d, Bent Tip 5.4 mm, Dissipative - Bernstein 5-864-135
BERNSTEIN
Original product
Net price (excl. VAT)
€18.72
Item
BS-5-864-135
Manufacturer no.
5-864-135
ESD · IEC 61340-5-1
Konformitätserklärung
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.5-864-135
EAN4250838532914
Customs tariff number82032000
ConditionNew
Article
BS-5-864-135
Frequently Bought Together
Assembling sensitive SMD components or optical parts such as lenses and mirrors calls for tweezers that neither scratch the surface nor cause electrostatic discharge. The 5-864-135 combines a flat, upward-bent tip 5.4 mm wide with a dissipative, PVC dip-insulated coating.
Advantages
- Flat, angular, upward-bent tip 5.4 mm wide for a non-slip grip.
- PVC dip-insulated tip protects lenses, prisms and mirrors from scratches.
- ESD coating with a surface resistance between 10^6 and 10^9 ohms for EPA use.
- Antimagnetic stainless steel SA with a matt, glare-free surface.
- Compact overall length of 105 mm and a weight of 14 g for fatigue-free work.
Technical Data
| Feature | Value |
|---|---|
| Tip | dissipative, ESD PVC dip-insulated |
| Tip shape | flat, angular, upward-bent, 5.4 mm wide, non-slip |
| Form | 46d |
| Material | stainless steel SA, antimagnetic |
| ESD coating | dissipative between 10^6 and 10^9 ohms |
| Surface | matt, smooth and glare-free |
| Overall length | 105 mm |
| Weight | 14 g |
Application
- Gripping and positioning SMD components in electronics assembly.
- Handling laser optics, lenses, mirrors and prisms without scratches or fingerprints.
- Working with sensitive crystals and optical components in ESD-protected areas.
Standards and Delivery Data
- Surface resistance 10^6 to 10^9 ohms per DIN EN 61340-5-1
- EAN 4250838532914
- Customs tariff number 82032000
- Country of origin Italy
| Certification | IEC 61340-5-1 |
|---|---|
| ESD version | ESD (antistatic) |
| Manufacturer Nr. | 5-864-135 |
| Manufacturer | Bernstein |
| EAN | 4250838532914 |
| Weight | 0.009900 |
| HS-Code | 82032000 |
| GPSR manufacturer information | BERNSTEIN Werkzeugfabrik Industriehof Trecknase 1 DE-42897 Remscheid www.bernstein-werkzeuge.de |
| Article authenticity | Original product |
| Condition of article | New |
