ESD LED Magnifying Lamp WAVE 5 Diopters, Dissipative Housing 10^4 to 10^9 Ohm - Bernstein 9-161
The ESD LED magnifying lamp WAVE combines a 5 diopter glass lens with two LED modules totaling 13 watts in a dissipative housing rated 10^4 to 10^9 ohm. It delivers shadow-free illumination up to 4600 lux and is suitable for ESD workstations in accordance with DIN EN 61340-5-1.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
At the ESD workstation, sensitive components must not be exposed to an electrostatic field above 100 V/cm. The ESD LED magnifying lamp WAVE, with its 5 diopter glass lens and dissipative housing, provides shadow-free, safe illumination in accordance with DIN EN 61340-5-1.
Advantages
- Two LED modules with a CRI above 80 and 4000 K for natural color rendering
- Black housing, dissipative at 10^4 to 10^9 ohm per DIN EN 61340-5-1
- Glass lens with 5 diopters, expandable with attachment lenses of 4, 6 or 10 diopters
- 1050 mm articulated arm with table clamp for flexible positioning
- Only 13 watts of power at 240 V for shadow-free incident light
Application
The magnifying lamp suits any work in the electrostatically protected area (EPA) where loupes and lighting are used directly on the component, such as final inspection of boards and assemblies.
Standards and Delivery Data
- DIN EN 61340-5-1, EPA suitable
- EAN 4250838511025
- Customs tariff number 90138080
- Country of origin Norway
Technical data
| Feature | Value |
|---|---|
| LED modules | 2 lamps, CRI above 80, 4000 K |
| Housing color | Black, dissipative 10^4 to 10^9 ohm |
| Glass lens | 5 diopters |
| Expansion | Attachment lenses of 4, 6 or 10 diopters |
| Focal length | 297 mm |
| Lamp power | 13 watts |
| Voltage | 240 V |
| Mounting | With table clamp |
| Arm length | 1050 mm |
| Illuminance | 4600 lux |
| Shutoff | Automatic after 4 or 9 hours |
| Weight | 4600 g |
| Manufacturer | Bernstein |
| Manufacturer Nr. | 9-161 |
| EAN | 4250838511025 |
| HS-Code | 90138080 |
| GPSR manufacturer information | BERNSTEIN Werkzeugfabrik Industriehof Trecknase 1 DE-42897 Remscheid www.bernstein-werkzeuge.de |
| Condition of article | New |
| Article authenticity | Original product |
| ESD version | ESD (antistatic) |
| Certification | IEC 61340-5-1 |
| Colour temperature | 4000K |
| Mounting type | Articulated arm, Table clamp |
| Magnification (dioptres) | 5 dpt |
| Operating voltage | 100 V |
