This ESD set combines the screw-on ball joint vise SPANNFIX with an earth bonding plug and a 1.8 m grounding cable (1 megohm) for direct connection to the grounding point. The vise holds with 1470 N clamping force at a 70 mm clamping width, and the dissipative ESD coating (10^7 to 10^8 ohm) makes it EPA suitable.
ESD Ball Joint Vise SPANNFIX Set for Screwing On with Earth Bonding Plug and Cable - Bernstein 9-215-ESD-SET1
BERNSTEIN Original product
Net price (excl. VAT)
€194.52
Item BS-9-215-ESD-SET1
Manufacturer no. 9-215-ESD-SET1
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.9-215-ESD-SET1
EAN4250838529716
Customs tariff number82057000
ConditionNew
Article
BS-9-215-ESD-SET1
Frequently Bought Together
Permanently bolted ESD workstations need not only a dissipative vise but also its link to the grounding point. This set supplies the screw-on ball joint vise SPANNFIX together with an earth bonding plug and a 1.8 m grounding cable, matched and ready to use.
Advantages
- Ball joint vise with 1470 N clamping force at a 70 mm clamping width, rotatable 360° and tiltable by ± 45°
- Dissipative black ESD powder coating at 10^7 to 10^8 ohm for EPA-suitable workstations
- Solid screw-on mounting via a 150 x 106 mm base plate with four 9 mm holes
- Earth bonding plug with 2x10 mm and M5 connection for flexible mounting at the grounding point
- 1.8 m grounding cable with 1 megohm protective resistor and two 10 mm push studs
Technical Data
| Feature | Value |
|---|---|
| Ball joint | Rotatable 360°, steplessly lockable quick release, Made in Germany |
| Mounting | Screw-on, base plate 150 x 106 mm, 4 through-holes x 9 mm |
| Jaws | 50 mm ESD plastic jaws with grip |
| Clamping width | 70 mm |
| Clamping depth | 38 mm |
| Clamping force | 1470 N |
| Tilt angle | ± 45° |
| Accessories | Spare jaws Art. 9-900-E50-ESD (pair) |
| Material | Cast aluminum with black ESD powder coating, dissipative 10^7 to 10^8 ohm |
| Dimensions | approx. 220 x 180 x 115 mm |
| Weight | 1400 g |
| Maximum torque | ball dia. 40 mm approx. 24 Nm, ball dia. 60 mm approx. 100 Nm |
Application
For soldering, testing and assembly workstations in electrostatically protected areas (ESD workplace / ESD protection zone) where the vise and its grounding connection are needed together.
Scope of Delivery
- 9-215-ESD ball joint vise SPANNFIX for screwing on, dissipative
- 9-359-2 ESD earth bonding plug 2x10 mm and M5 socket
- 9-343-1 ESD grounding cable 1 megohm, 1800 mm, 2 push studs 10/10 mm
Standards and Delivery Data
- EPA suitable for electrostatically protected areas
- EAN 4250838529716
- Customs tariff number 82057000
- Country of origin Germany
| ESD version | ESD (antistatic) |
|---|---|
| Manufacturer Nr. | 9-215-ESD-SET1 |
| Manufacturer | Bernstein |
| EAN | 4250838529716 |
| Weight | 1.400000 |
| HS-Code | 82057000 |
| GPSR manufacturer information | BERNSTEIN Werkzeugfabrik Industriehof Trecknase 1 DE-42897 Remscheid www.bernstein-werkzeuge.de |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
