DE 5/OC Rotary Unit for Workpiece Carrier Transport - Bosch Rexroth 3842998864
Datasheet (PDF)
The product may differ from the illustration
The DE 5/OC rotary unit provides horizontal rotation and transfer of workpiece carriers within assembly conveyor systems. It handles heavy workpiece pallets up to 400 kg and supports branch-offs and crossings in the line layout. Supplied ready to install including supports; operates at 5-6 bar compressed air.

DE 5/OC Rotary Unit for Workpiece Carrier Transport - Bosch Rexroth 3842998864

BOSCH REXROTH Original product
Net price (excl. VAT)
€11,518.05
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842998864
Manufacturer no. 3842998864
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998864
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998864

The DE 5/OC rotary unit is a module for the horizontal rotation and transport of workpiece carriers in assembly automation lines. It allows branch-offs and crossings within the conveyor layout and is rated for heavy workpiece pallets up to 400 kg. The unit is delivered ready to install including supports.

  • Capacity up to 400 kg - suitable for heavy workpiece pallets
  • Flexible rotation: 90°, 180° or 270° selectable (cycle times 4, 7 and 10 s respectively)
  • Track width in direction of transport [b]: 455, 650 or 845 mm
  • Ready to install with supports; protective covers available as an option
  • Straight pneumatic connection, hose dia. 6 mm; operating pressure 5-6 bar

Technical data

ParameterValue
Track width, transport direction [b]455 / 650 / 845 mm
Length in transport direction [lT]455 / 650 / 845 / 1040 mm
Belt section length [L]1000 / 1310 / 1180 mm
Transportation height [H]585 ... 1400 mm
Dimension without protective cover [D1]1140 / 1500 / 1500 mm
Dimension with protective cover [D2]1156 / 1516 / 1516 mm
Rotary movement time90°: 4 s / 180°: 7 s / 270°: 10 s
Pneumatic straight connectiondia. 6 mm
Operating pressure [pmin / pmax]5 / 6 bar
Maximum pallet load400 kg
Weightapprox. 0.1 kg (module weight; total weight depends on configuration)
Delivery conditionReady to install incl. supports; protective covers optional
More Information
Manufacturer Nr. 3842998864
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.100000
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
