The Rotary Unit DE 2 BG 3 handles horizontal rotation of workpiece carriers through 90°, 180°, or 270° within conveyor assembly line systems. Supplied ready to install including supports, it accommodates heavy workpiece pallets up to 160 kg and covers transport heights from 585 to 1400 mm. Pneumatic actuation operates at 5 to 6 bar via a 6 mm push-in fitting.

Rotary Unit DE 2 BG 3 - Swivel Module for Workpiece Carriers up to 160 kg - Bosch Rexroth 3842998873

Name: Rotary Unit DE 2 BG 3 - Swivel Module for Workpiece Carriers up to 160 kg - Bosch Rexroth 3842998873
Brand: Bosch Rexroth
SKU: BRR-3842998873
Price: 16973.97 EUR
Availability: InStock

BOSCH REXROTH Original product

Net price (excl. VAT)

€16,973.97

Excl. 19% VAT , excl. Shipping Cost

Available Fast shipping

Item BRR-3842998873

Manufacturer no. 3842998873

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.3842998873

Country of originGermany

Customs tariff number84313900

ConditionNew

Article

BRR-3842998873

Frequently Bought Together

This Item: Rotary Unit DE 2 BG 3 - Swivel Module for Workpiece Carriers up to 160 kg - Bosch Rexroth 3842998873
€16,973.97
Excl. 19% VAT , excl. Shipping Cost
Belt Section BS 2/R-H - Bosch Rexroth 3842998939
€3,913.48
Excl. 19% VAT , excl. Shipping Cost
Double Ball Stop Latch Slot 10, 80x80x18 mm, White Aluminum RAL 9006 - Bosch Rexroth 3842558570
€40.71
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

The Rotary Unit DE 2 BG 3 is a pneumatically actuated swivel module for horizontal rotation and transport of workpiece carriers in size-3 linked assembly line systems. It enables branch-offs and crossings for heavy workpiece pallets and is delivered ready to install, complete with supports.

Rotation angles of 90°, 180°, and 270° covered by one module
Maximum workpiece pallet weight 160 kg
Pneumatic drive - no additional electric motor required
Ready to install including supports; protective covers available as an option
Transport height adjustable from 585 to 1400 mm

Technical data

Parameter	Value
Track width in direction of transport [b]	480 / 640 / 800 mm
Length in direction of transport [lT]	480 / 640 / 800 mm
Belt section length [L]	1001 / 903 / 761 mm
Diameter without protective cover [D1]	1140 mm
Diameter with protective cover [D2]	1156 mm
Transportation height [H]	585 ... 1400 mm
Pneumatic straight connection	6 mm push-in
Operating pressure	5 ... 6 bar
Rotary movement time 90°	4 s
Rotary movement time 180°	7 s
Rotary movement time 270°	10 s
Max. workpiece pallet weight [mG]	160 kg
Delivery condition	Ready to install incl. supports; protective covers optional

Information

More Information
Manufacturer Nr.	3842998873
Manufacturer	Bosch Rexroth
Country of Manufacture	Germany
Weight	0.100000
HS-Code	84313900
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity	Original product
Condition of article	New
