EC motor EC302, size 2, installation length 197 mm - Bosch Rexroth 0608701016

Building a size 2 fastening spindle starts with the drive. The EC302 EC motor powers the planetary gearbox, measurement transducer and output while taking up only 197 mm of installation length. At 0.72 kg the spindle stays light and can be packed closely in multi-spindle stations.

Benefits

• Short 197 mm installation length for spindles with limited space
• 0.72 kg net weight reduces the load on spindle mounting and feed unit
• Electronically commutated motor, no brush wear
• Module of Tightening System 350: motor, gearbox, transducer and output are combined to suit the joint

Specifications

Applications

• Fastening spindles in automated multi-spindle stations
• Smallest spindle size for the lower torque range of the system
• Replacement for existing size 2 spindles

System compatibility

• Rexroth Tightening System 350, size 2
• Combines with 2GE planetary gearboxes such as 2GE19 or 2GE26
• Driven by an LTS350D or LTE350D servo amplifier
