Planetary gearbox 2GE26, size 2, ratio 25.5 - Bosch Rexroth 0608720038

Between the EC motor and the transducer, the gearbox decides how much torque and which speed reach the output. The 2GE26 reduces at 25.5 to 1, making it the size 2 choice when torque matters more than speed. At 50.9 mm installation length it adds very little to the spindle.

Benefits

• 25.5 reduction ratio for higher output torque than the 2GE19 in the same size
• Short 50.9 mm installation length
• Light module at 0.32 kg net weight
• Typical efficiency 0.9 according to the manufacturer

Specifications

Applications

• Size 2 spindles where torque is the priority
• Multi-spindle systems for small part assembly

System compatibility

• Rexroth Tightening System 350, size 2
• Driven by the EC302 EC motor
• Alternative with lower ratio: 2GE19
