Planetary gearbox 2GE19, size 2, ratio 18.9 - Bosch Rexroth 0608720043

Short cycle times need high output speed, especially on long rundown paths. The 2GE19 planetary gearbox reduces at only 18.9 to 1, so in size 2 more motor speed reaches the output than with the 2GE26. At 0.93, its typical efficiency is higher than that of the higher-ratio versions.

Benefits

• 18.9 reduction ratio for higher output speed and shorter rundown time
• Typical efficiency 0.93, less power lost in the gearbox
• Same 50.9 mm installation length as the 2GE26, swap without changing spindle length
• Net weight 0.32 kg

Specifications

Applications

• Size 2 spindles focused on cycle time
• Joints with long rundown and moderate final torque

System compatibility

• Rexroth Tightening System 350, size 2
• EC302 EC motor
• Higher-torque alternative: 2GE26
