Horizontal curve VarioFlow plus, 90°, R 500 mm, 90HAA15R500I100O100 - Bosch Rexroth 3841055575
Horizontal curve 90HAA15R500I100O100 for VarioFlow plus: change of direction by 90° with radius 500 mm. Ready-made curve element for line layout without special construction.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The horizontal curve 90HAA15R500I100O100 redirects the product flow of a VarioFlow plus conveyor by 90° with a radius of 500 mm in the horizontal plane.
Benefits
- Change of direction 90°, radius R 500 mm
- Part of the VarioFlow conveyor system
- Clearly reorderable by material number
Applications
VarioFlow plus chain conveyors in packaging, food, pharmaceutical and assembly lines.
Selection note
The assignment to your existing installation is made via manufacturer part number 3841055575. Compare designation and material number with the parts list, spare parts list or rating plate of the installed component.
Technical data
| Manufacturer | Bosch Rexroth |
|---|---|
| Manufacturer part number | 3841055575 |
| Designation | Horizontal curve 90HAA15R500I100O100 |
| Weight | 2.2 kg |
| Manufacturer Nr. | 3841055575 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
