Drilling Jig Groove 8 for Miter-Cut Profiles, Aluminum - Bosch Rexroth 3842516729
Datasheet (PDF)
The product may differ from the illustration
Aluminum drilling jig for profile groove 8, used to position fastening holes (ø 11 mm) on miter-cut profiles. It supports the precise fitting of bendable quick connectors. Fastening material is included in the scope of delivery.

Drilling Jig Groove 8 for Miter-Cut Profiles, Aluminum - Bosch Rexroth 3842516729

BOSCH REXROTH Original product
Net price (excl. VAT)
€111.63
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842516729
Manufacturer no. 3842516729
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842516729
Country of originGermany
Customs tariff number90178090
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842516729
Frequently Bought Together
Total price

The Bosch Rexroth drilling jig helps position fastening holes (ø 11 mm) accurately on miter-cut aluminum profiles with groove 8. It is intended for users in profile and machine frame construction who need to fit bendable quick connectors reliably.

  • For profile groove 8 (N8)
  • Positions ø 11 mm holes for bendable quick connectors
  • Fastening material included in the scope of delivery

Technical data

MaterialAluminum
Profile slot8 (N8)
Hole diameterø 11 mm
Fastening material1x clamping lever M6x25, 1x T-nut groove 8 M6
Scope of deliveryIncl. fastening material
Packaging unit1
Weight0.18 kg
More Information
Manufacturer Nr.3842516729
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.180000
HS-Code90178090
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
