Load-bearing extruded profile in anodized aluminum for longitudinal transport in the TS 2plus transfer system. With profile slot 10 and a length of 6070 mm, it forms the basis of the section units for belt and timing-belt conveying.
Conveyor section profile SP 2/B-100, anodized aluminum, slot 10, 6070 mm - Bosch Rexroth 3842532608
BOSCH REXROTH Original product
Net price (excl. VAT)
€7,431.61
Item BRR-3842532608
Manufacturer no. 3842532608
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842532608
Country of originSlovakia
Customs tariff number76042100
ConditionNew
Article
BRR-3842532608
Frequently Bought Together
- This Item: €7,431.61
- Slide rail SF outer, PVC, L=3000 mm - Bosch Rexroth 3842537806 €13.84
- Idle Roller D32SK ESD Yellow, Lean Conveyor, PA - Bosch Rexroth 3842537963 €2.13
Total price
The SP 2/B-100 conveyor section profile is a load-bearing extruded profile for longitudinal transport in the Bosch Rexroth TS 2plus transfer system. It forms the basis of the section units for belt and timing-belt conveying and is intended for design engineers and maintenance teams in material flow.
- Anodized aluminum for lasting corrosion protection and a stable surface
- Profile slot 10 for mounting connectors and add-on elements
- Standard length 6070 mm, supplied as a packaging unit of 16 pieces
Technical data
| Profile slot | 10 |
| Length [L] | 6070 mm |
| Material | Aluminum, anodized |
| Color | Natural |
| Profile surface [A] | 11.9 cm² |
| Mass [m] | 3.2 kg |
| Area moment of inertia X [Ix] | 95.1 cm⁴ |
| Area moment of inertia Y [Iy] | 30.4 cm⁴ |
| Moment of resistance X [Wx] | 20 cm³ |
| Moment of resistance Y [Wy] | 13.5 cm³ |
| Delivery unit | 16 |
| Condition on delivery | Packaging unit in standard length |
| Recommended accessories | Roller elements, Cross Connector QV 2 |
| Weight | 338 kg |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842532608 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Slovakia |
| Weight | 338.000000 |
| HS-Code | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
