Conveyor section profile SP2/B, anodized aluminum, slot 10, 6070 mm - Bosch Rexroth 3842532695
Datasheet (PDF)
The product may differ from the illustration
Conveyor section profile SP2/B for the TS 2plus transfer system, made of anodized aluminum with profile slot 10. It forms the load-bearing track for longitudinal transport with belt or toothed belt. Supplied in the 6070 mm standard length, delivery unit 16 pieces.

Conveyor section profile SP2/B, anodized aluminum, slot 10, 6070 mm - Bosch Rexroth 3842532695

BOSCH REXROTH Original product
Net price (excl. VAT)
€4,752.09
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842532695
Manufacturer no. 3842532695
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842532695
Country of originSweden
Customs tariff number76042100
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842532695
Frequently Bought Together
Total price

The SP2/B conveyor section profile is a load-bearing component of the section units in the Bosch Rexroth TS 2plus transfer system, intended for machine and special-purpose builders using longitudinal belt and toothed-belt transport.

  • Anodized aluminum for high rigidity at low weight
  • Profile slot 10 to accept connectors and add-on parts
  • Standard length 6070 mm, delivery unit 16 pieces

Technical data

AttributeValue
Condition on deliveryPackaging unit in standard length
Profile slot10
ColorNatural
Delivery unit16
Length L6070 mm
Profile surface A10.4 cm²
Mass m2.8 kg
Moment of resistance Wx12.1 cm³
Moment of resistance Wy11.5 cm³
Area moment of inertia Ix49.6 cm⁴
Area moment of inertia Iy25.8 cm⁴
MaterialAluminum, anodized
Recommended accessoriesRoller elements, Cross Connector QV 2
Weight310 kg
More Information
ExecutionTEC
Manufacturer Nr.3842532695
ManufacturerBosch Rexroth
Country of ManufactureSweden
Weight310.000000
HS-Code76042100
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
