Belt connector for joining the drive belt ends in the LF12S/C and LF20 S/C roller guides. Made of black painted aluminum for profile slot 10 and supplied with the complete fastening material. Delivered as a packaging unit of 2.
Belt Connector LF12S/C and LF20 S/C, Aluminum, Slot 10 - Bosch Rexroth 3842535680
BOSCH REXROTH
Original product
Net price (excl. VAT)
€93.88
Item
BRR-3842535680
Manufacturer no.
3842535680
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842535680
Country of originGermany
Customs tariff number82057000
ConditionNew
Article
BRR-3842535680
Frequently Bought Together
The belt connector joins the ends of the drive belt in the LF12S/C and LF20 S/C roller guides into a closed loop. It is intended for design engineers and maintenance staff building or servicing linear guides in the Bosch Rexroth aluminum profile system.
- Secure, positive connection of the belt ends
- Black painted aluminum for use in profile slot 10
- Complete fastening material included in delivery
Technical data
| Attribute | Value |
|---|---|
| Profile slot | 10 |
| Material | Aluminum, painted |
| Color | Black |
| Mass [m] | 0.64 kg |
| Weight | 0.665 kg |
| Packaging unit | 2 |
| Scope of delivery | incl. fastening material (FS) |
| Fastening material | 4x centering bolt D10/5, 2x cylinder head screw DIN7984-M12x40, 2x cylinder head screw DIN7984-M8x40, 2x washer DIN125-A8.4, 2x T-nut groove 10 M8, 2x countersunk screw DIN7991-M8x30, 2x cap D18 |
| Norm | DIN 125, DIN 7984, DIN 7991 |
|---|---|
| Manufacturer Nr. | 3842535680 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.665000 |
| Colour | Black |
| HS-Code | 82057000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
