Conveyor Section Profile 90+ AL, Anodized Aluminum, Slot 10, L 6070 mm - Bosch Rexroth 3842546644
Datasheet (PDF)
The product may differ from the illustration
Section profile for the VarioFlow plus chain conveyor system in size 90. Made of anodized aluminum with profile slot 10 and a 6070 mm delivery length. It forms the load-bearing conveyor section that guides the slide rail and conveyor chain.

Conveyor Section Profile 90+ AL, Anodized Aluminum, Slot 10, L 6070 mm - Bosch Rexroth 3842546644

BOSCH REXROTH Original product
Net price (excl. VAT)
€7,031.11
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842546644
Manufacturer no. 3842546644
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842546644
Country of originGermany
Customs tariff number76042100
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842546644
Frequently Bought Together
Total price

The Conveyor Section Profile 90+ AL is the load-bearing base profile of a conveyor section in the Bosch Rexroth VarioFlow plus chain conveyor system. Designed for the aluminum build in size 90, it carries the slide rail and conveyor chain. Intended for designers and system builders planning modular conveyor lines.

  • anodized aluminum, corrosion-resistant and low-maintenance
  • profile slot 10 for mounting system accessories
  • standard delivery length of 6070 mm, supplied in packaging units

Technical data

Size [b]90 mm
Length [L]6070 mm
Profile slot10
MaterialAluminum, anodized
ColorNatural
Mass [m]2.42 kg/m
Area moment of inertia X [lx]24.4 cm⁴
Area moment of inertia Y [ly]102.86 cm⁴
Delivery unit12 pieces
Required accessoriesSlide rail, profile connector
Recommended accessoriesCover profile
Weight (packaging unit)180.7 kg
More Information
ExecutionTEC
Manufacturer Nr.3842546644
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight180.700000
HS-Code76042100
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
