Horizontal curve 65+ AL, 45° R700, VarioFlow plus - Bosch Rexroth 3842547073

BOSCH REXROTH Original product
Net price (excl. VAT)
€427.94
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842547073
Manufacturer no. 3842547073
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842547073
Country of originGermany
Customs tariff number76109090
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842547073
Horizontal curve 65+ AL, 45° R700, VarioFlow plus - Bosch Rexroth 3842547073
The product may differ from the illustration
Horizontal 45° curve in size 65 for the VarioFlow plus chain conveyor system. The anodized aluminum profile redirects the conveyor chain in the horizontal plane. Supplied fully assembled with fastening material for mounting to the AL section profile.
Frequently Bought Together
Total price

The horizontal curve 65+ redirects the conveyor chain of the VarioFlow plus chain conveyor system by 45° in the horizontal plane. It is designed for size 65 with curve radius R700 and connects straight track sections into continuous conveyor loops.

  • Deflection angle 45° at curve radius R700
  • Profile in anodized aluminum, corrosion-resistant and lightweight
  • supplied fully assembled, ready to connect
  • incl. fastening material for mounting to the AL section profile

Technical data

Deflection angle45°
Size (b)65 mm
Dimension (A)331.2 mm
Actual chain length2x 0.75 m
Effective sliding rail length4x 0.75 m
Profile materialAluminum, anodized
Profile connector materialSteel, galvanized
Cross connector materialDiecast aluminum
Scope of deliveryincl. fastening material for mounting to the AL section profile
Delivery informationfully assembled
Required accessoriesSlide rail (length calculation)
Weight2.06 kg
More Information
Execution TEC
Manufacturer Nr. 3842547073
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 2.060000
HS-Code 76109090
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
