Vertical Curve VarioFlow plus AL, Size 90, 45° R500 - Bosch Rexroth 3842547092
Datasheet (PDF)
The product may differ from the illustration
Pre-assembled vertical curve for the VarioFlow plus chain conveyor system in aluminum, size 90, with a 45° deflection angle and R500 radius. It redirects the conveyor chain in the vertical plane. Supplied fully assembled, including fastening material for mounting to the AL section profile.

Vertical Curve VarioFlow plus AL, Size 90, 45° R500 - Bosch Rexroth 3842547092

BOSCH REXROTH Original product
Net price (excl. VAT)
€367.65
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842547092
Manufacturer no. 3842547092
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842547092
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842547092

The VarioFlow plus AL vertical curve is a pre-assembled deflection unit for the VarioFlow plus chain conveyor system in an aluminum design. It guides the conveyor chain in the vertical plane with a 45° deflection angle and is designed for size 90. It is used in conveyor layouts where height differences have to be bridged.

  • Supplied fully assembled, including fastening material for mounting to the AL section profile
  • Anodized aluminum profile with galvanized profile connectors
  • Defined chain and slide rail guidance over the effective component length

Technical data

Deflection angle45°
Size90 mm
Dimension A548.7 mm
Actual chain length2x 0.59 m
Effective sliding rail length4x 0.59 m
ProfileAluminum, anodized
Profile connectorSteel, galvanized
Cross connectorDiecast aluminum
Support profile from size 160Non-rusting steel 1.4301
Scope of deliveryIncl. fastening material for mounting to AL section profile
Delivery conditionFully assembled
Required accessoriesSlide rail (length calculation)
Weight1.78 kg
More Information
Execution TEC
Manufacturer Nr. 3842547092
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 1.780000
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
