Vertical Curve 240, Aluminum, 7.5° R500, VarioFlow plus - Bosch Rexroth 3842547104
Datasheet (PDF)
The product may differ from the illustration
Vertical curve for the VarioFlow plus chain conveyor system in size 240. The anodized aluminum profile deflects the conveyor chain by 7.5° in the vertical plane. Supplied fully assembled for direct mounting to the AL section profile.

Vertical Curve 240, Aluminum, 7.5° R500, VarioFlow plus - Bosch Rexroth 3842547104

BOSCH REXROTH Original product
Net price (excl. VAT)
€332.35
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842547104
Manufacturer no. 3842547104
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842547104
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842547104
Frequently Bought Together
Total price

The Vertical Curve 240 is a pre-assembled deflection element for the Bosch Rexroth VarioFlow plus chain conveyor system. It guides the conveyor chain through 7.5° in the vertical plane and is suited to height changes within a conveyor line.

  • Anodized aluminum profile for stable chain guidance
  • Supplied fully assembled, incl. fastening material for mounting to the AL section profile
  • Support profile in non-rusting steel 1.4301 from size 160

Technical data

Deflection angle7.5°
Size240 mm
Dimension A268.9 mm
Actual chain length2x 0.26 m
Effective sliding rail length8x 0.26 m
ProfileAluminum, anodized
Profile connectorSteel, galvanized
Cross connectorDiecast aluminum
Support profile from size 160Non-rusting steel 1.4301
Scope of deliveryIncl. fastening material for mounting to the AL section profile
Delivery stateFully assembled
Required accessoriesSlide rail (length calculation)
Weight2.342 kg
More Information
Execution TEC
Manufacturer Nr. 3842547104
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.100000
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
