The product may differ from the illustration
Pre-assembled return unit for the VarioFlow plus chain conveyor system in the aluminum range. It guides the conveyor chain back at the end of a line. With the required accessories it can also be used as a drive.
Return Unit 90+ AL, VarioFlow plus, Track Width 90 mm - Bosch Rexroth 3842547517
BOSCH REXROTH Original product
Net price (excl. VAT)
€535.32
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842547517
Manufacturer no. 3842547517
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842547517
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842547517
Frequently Bought Together
- This Item: €535.32Excl. 19% VAT , excl. Shipping Cost
- Cam wheel 90+ AL, 180° deflection, VarioFlow plus - Bosch Rexroth 3842547055 €497.07Excl. 19% VAT , excl. Shipping Cost
- Conveyor Section Profile 65+ AL, Variable Length 50-6000 mm, Anodized Aluminum - Bosch Rexroth 3842996022-1000 €115.34Excl. 19% VAT , excl. Shipping Cost
Total price
The Return Unit 90+ AL is a fully assembled return unit for the VarioFlow plus chain conveyor system in the aluminum range. It returns the conveyor chain at the end of a conveyor line and, with the required accessories, can also be used as a drive.
- Housing made of powder-coated die-cast aluminum
- Track width 90 mm in direction of transport
- Ball bearing in non-rusting steel 1.4301/FDA
- Supplied fully assembled, including fastening material
Technical data
| Size [b] | 90 mm |
| Track width in direction of transport [b] | 90 mm |
| Effective sliding rail length | 0.742 m |
| Actual chain length | 2x 0.2 m |
| Housing | Die-cast aluminum, powder-coated |
| Chain wheel | PA |
| Chain guide | PA |
| Hexagonal shaft (up to size 160) | PA |
| Connector | Steel, galvanized |
| Ball bearing | Non-rusting steel 1.4301/FDA |
| Scope of delivery | Incl. fastening material |
| Delivery condition | Fully assembled |
| Weight | 1.89 kg |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3842547517 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 1.890000 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
