Frame Profile 30x30 WG40 2x[M8+7.8], 1000 mm - Bosch Rexroth 3842992978-1000

Name: Frame Profile 30x30 WG40 2x[M8+7.8], 1000 mm - Bosch Rexroth 3842992978-1000
Brand: Bosch Rexroth
SKU: BRR-3842992978-1000
Price: 35.32 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Anodized aluminum frame profile 30x30 mm for the Bosch Rexroth EcoSafe WG40 safety guard system, supplied at 1000 mm and cuttable from 100 to 6000 mm. Two M8 connecting channels with 7.8 mm bore enable rigid frame corners and wall connections; assembly requires central bolt, woven wire grille, and spring clamping elements.

Net

€35.32

excl. VAT

Item BRR-3842992978-1000

Manufacturer no. 3842992978-1000

Question about this item

Datasheet (PDF) 8 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Frame Profile 30x30 WG40 is the primary structural element for guard panel walls in the Bosch Rexroth EcoSafe system. The anodized aluminum section accepts woven wire grilles securely and assembles tool-efficiently using a central bolt and spring clamping elements.

30x30 mm cross-section, slot 8 - fully compatible with all EcoSafe WG40 accessories
Two M8 connecting channels with 7.8 mm bore for rigid corner joints and wall attachment
Flexible cut-to-length: available from 100 to 6000 mm, delivered as 1 piece
Anodized aluminum construction - corrosion-resistant, lightweight and durable
Area moments of inertia lx 2.4 cm⁴ / ly 2.9 cm⁴ for dimensionally stable frame structures

Technical data

Property	Value
Profile cross-section	30 x 30 mm
Profile slot	8
Length min. [L min]	100 mm
Length max. [L max]	6000 mm
Delivery unit	1 piece
Material	Aluminum, anodized
Mass [m]	0.9 kg/m
Profile surface [A]	3.2 cm²
Area moment of inertia [lx]	2.4 cm⁴
Moment of resistance [Wx]	1.5 cm³
Area moment of inertia [ly]	2.9 cm⁴
Moment of resistance [Wy]	1.8 cm³
Required accessories	Central bolt, woven wire grille, spring clamping elements
Weight	0.01 kg
Manufacturer	Bosch Rexroth
Manufacturer Nr.	3842992978-1000
HS-Code	76109090
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
ESD version	TEC
