Material Chute Profile 90x45 mm, Anodized Aluminum, 50-3000 mm Cut Length - Bosch Rexroth 3842993071
Datasheet (PDF)
The product may differ from the illustration
Anodized aluminum profile 90x45 mm for Vario bin systems, supplied in variable cut lengths from 50 mm to 3000 mm. Profile cross-section area 7 cm², mass 1.8 kg/m - for building material chutes in manual assembly workstations.

Material Chute Profile 90x45 mm, Anodized Aluminum, 50-3000 mm Cut Length - Bosch Rexroth 3842993071

BOSCH REXROTH Original product
Net price (excl. VAT)
€5.27
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842993071
Manufacturer no. 3842993071
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842993071
Country of originGermany
Customs tariff number76041090
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842993071
Frequently Bought Together
Total price

The 90x45 profile forms the load-bearing structure for material chutes within the Bosch Rexroth Vario bin system. Supplied to a cut length specified at order, it adapts precisely to workstation depths and shelf spacing in manual production environments.

  • Variable length from 50 mm to 3000 mm - no fixed grid pitch, cut to order
  • Aluminum, anodized - resistant to corrosion, oils, and common cleaning agents
  • Profile area 7 cm² and area moments of inertia lx 20.7 cm⁴ / ly 54.3 cm⁴ - sufficient rigidity for part bins in manual assembly operation
  • System-compatible with the full Bosch Rexroth Vario bin range

Technical data

AttributeValue
Profile cross-section90 x 45 mm
Length min [L min]50 mm
Length max [L max]3000 mm
Condition on deliveryVariable length
Delivery unit1
Profile surface [A]7 cm²
Area moment of inertia in x-direction [lx]20.7 cm⁴
Area moment of inertia in y-direction [ly]54.3 cm⁴
Mass [m]1.8 kg/m
MaterialAluminum, anodized
More Information
Manufacturer Nr. 3842993071
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.000000
HS-Code 76041090
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
