Aluminium Profile 90x90 Material Chute, Anodized, Variable Length 50-3000 mm - Bosch Rexroth 3842993072-1000
Aluminium Profile 90x90 Material Chute, Anodized, Variable Length 50-3000 mm - Bosch Rexroth 3842993072-1000 Aluminium Profile 90x90 Material Chute, Anodized, Variable Length 50-3000 mm - Bosch Rexroth 3842993072-1000

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Aluminium Profile 90x90 Material Chute, Anodized, Variable Length 50-3000 mm - Bosch Rexroth 3842993072-1000

Bosch Rexroth ✓ Original product Brand new Made in Germany

Extruded anodized aluminium profile 90x90 mm for Vario part bins and manual assembly systems. Supplied in variable lengths from 50 to 3000 mm, cut to the required dimension. Mass 2.5 kg/m with area moment of inertia lx 118.8 cm⁴ for rigid chute structures.

Net
€123.83
excl. VAT
Item BRR-3842993072-1000
Manufacturer no. 3842993072-1000
Save Compare
Question about this item
Datasheet (PDF) 8 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The 90x90 aluminium profile (Material Chute) is a structural section for building Vario part bins and manual production systems within the Bosch Rexroth Assembly Technology modular range. The anodized surface provides lasting corrosion resistance and protects handled components from surface damage. Supplied in variable length - minimum 50 mm, maximum 3000 mm - the profile can be cut precisely to the required installation dimension, eliminating the need to stock fixed lengths.

  • Compatible with the full Bosch Rexroth Vario part bin range and MTpro planning software
  • Variable length 50 to 3000 mm - order exactly what you need, no offcut waste
  • Anodized aluminium: lightweight, corrosion-resistant, gentle on sensitive components
  • High bending stiffness: lx 118.8 cm⁴ / ly 88.1 cm⁴ for stable chute geometry under load
  • Mass 2.5 kg/m - weight-optimised with a profile cross-section of 9.6 cm²

Technical data

ParameterValue
Condition on deliveryVariable length
Length min (L min)50 mm
Length max (L max)3000 mm
Delivery unit1
Mass (m)2.5 kg/m
Profile surface (A)9.6 cm²
Area moment of inertia x-direction (lx)118.8 cm⁴
Area moment of inertia y-direction (ly)88.1 cm⁴
MaterialAluminium, anodized
Profile cross-section90 x 90 mm
Weight0.01 kg
ManufacturerBosch Rexroth
Manufacturer Nr.3842993072-1000
HS-Code76041090
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
ESD versionTEC

Downloads

Datasheet

Catalogue

Other

Accessories

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day. Ask a question
