Conveyor Section Profile 65+ AL, Variable Length 50-6000 mm - Bosch Rexroth 3842996022
Datasheet (PDF)
The product may differ from the illustration
Aluminum conveyor section profile, size 65 mm, for the VarioFlow plus chain conveyor system. Anodized finish, supplied to a variable cut length from 50 to 6000 mm. Slide rail and profile connector required; cover profile recommended.

Conveyor Section Profile 65+ AL, Variable Length 50-6000 mm - Bosch Rexroth 3842996022

BOSCH REXROTH Original product
Net price (excl. VAT)
€5.39
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842996022
Manufacturer no. 3842996022
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842996022
Country of originGermany
Customs tariff number76042100
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842996022
Frequently Bought Together
Total price

The 65+ AL section profile forms the load-bearing track for VarioFlow plus chain conveyors in the 65 mm size range. The anodized aluminum profile is cut to variable length, giving engineers precise control over conveyor layout without wasted material.

  • Variable length from 50 to 6000 mm - ordered to exact dimension, reducing on-site cutting and scrap
  • Anodized aluminum construction - corrosion-resistant, lightweight, and suited to long-term chain contact
  • 10 mm profile slot along the full length - accepts standard fixings and attachments at any position
  • High bending stiffness - area moment of inertia Ix 23.13 cm⁴ / Iy 45.81 cm⁴ for stable guidance over longer unsupported spans

Technical data

PropertyValue
Size [b]65 mm
Length min [L min]50 mm
Length max [L max]6000 mm
Mass [m]2.12 kg/m
Area moment of inertia Ix23.13 cm⁴
Area moment of inertia Iy45.81 cm⁴
Profile slot10 mm
MaterialAluminum, anodized
ColorNatural
Condition on deliveryVariable length
Required accessoriesSlide rail, Profile connector
Recommended accessoriesCover profile
More Information
Execution TEC
Manufacturer Nr. 3842996022
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.100000
HS-Code 76042100
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
