VarioFlow plus Aluminium Supporting Structure, 160/240/320 mm, L 75-6000 mm - Bosch Rexroth 3842996028
Datasheet (PDF)
The product may differ from the illustration
Variable-length aluminium supporting structure for the VarioFlow plus chain conveyor system, available in sizes 160, 240 and 320 mm. Cut-to-length supply from 75 mm to 6000 mm eliminates the need to stock multiple fixed lengths. Anodized finish provides corrosion resistance for demanding industrial environments.

VarioFlow plus Aluminium Supporting Structure, 160/240/320 mm, L 75-6000 mm - Bosch Rexroth 3842996028

BOSCH REXROTH Original product
Net price (excl. VAT)
€5.39
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842996028
Manufacturer no. 3842996028
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842996028
Country of originGermany
Customs tariff number76109090
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842996028
Frequently Bought Together
Total price

This anodized aluminium supporting structure forms the load-bearing track element of the VarioFlow plus chain conveyor system. Available in three sizes (160, 240 and 320 mm) and supplied to any required length between 75 mm and 6000 mm, it allows conveyor lines to be built precisely to layout without offcuts or the need to hold multiple standard lengths.

  • Three sizes (160 / 240 / 320 mm) from a single order reference - covers the full range of VarioFlow plus track widths
  • Continuously variable length from 75 mm to 6000 mm - exact match to line layout, no trimming waste
  • Anodized aluminium construction - lightweight, corrosion-resistant and suited to clean or controlled-environment assembly lines
  • High bending stiffness in y-direction (ly = 15.25 cm⁴) - stable chain guidance across longer support spans
  • Supplied as single piece at variable length - ready to install without further machining

Technical data

ParameterValue
Size [b]160 / 240 / 320 mm
Length min [L min]75 mm
Length max [L max]6000 mm
MaterialAluminum, anodized
ColorNatural
Area moment of inertia in x-direction [lx]1.92 cm⁴
Area moment of inertia in y-direction [ly]15.25 cm⁴
Mass [m]0.69 kg/m
Delivery unit1
Condition on deliveryVariable length
More Information
ExecutionTEC
Manufacturer Nr.3842996028
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.100000
HS-Code76109090
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
