Height-adjustable leg set for conveyor and belt sections, made from extruded aluminium profile. Support width up to 175 mm, leg height adjustable from 200 to 1200 mm. ESD-suitable; supplied with height-adjustable bases and fastening material, not pre-assembled.
Leg Set SZ 1/L, height-adjustable, ESD-suitable - Bosch Rexroth 3842996335
BOSCH REXROTH Original product
Net price (excl. VAT)
€111.68
Item BRR-3842996335
Manufacturer no. 3842996335
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842996335
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842996335
Frequently Bought Together
- This Item: €111.68
- Strut Profile 30x30 2NVS, Slot 8, Anodized Aluminium, L 50-6070 mm - Bosch Rexroth 3842993706 €2.82
- Workpiece Pallet WT 4/F - Bosch Rexroth 3842998060 €51.11
Total price
The Leg Set SZ 1/L from Bosch Rexroth provides stable support for conveyor and belt sections while allowing flexible height adjustment to suit varying workstation and line layouts - from 200 mm up to 1200 mm leg height. The extruded aluminium profile construction is ESD-suitable, making the leg set appropriate for electronics assembly environments and dry rooms (relative humidity below 1 rF).
- Leg height 200 to 1200 mm continuously adjustable; preferred values 80, 120, 160 mm
- Track width in transport direction 80 to 160 mm; support width BSZ max 175 mm
- ESD-suitable for sensitive electronics production environments
- Supplied with height-adjustable bases and fastening material for conveyor or belt section installation
- Single-track section: B = b + 15 mm
- Required accessories (ordered separately): foundation bracket and floor dowel
Technical data
| Specification | Value |
|---|---|
| Support width BSZ max | 175 mm |
| Track width (transport direction) b min | 80 mm |
| Track width (transport direction) b max | 160 mm |
| Leg height hSZ min | 200 mm |
| Leg height hSZ max | 1200 mm |
| Transportation height H | 260 to 2000 mm |
| Preferred values | 80, 120, 160 mm |
| Installation location AO | 62.5 |
| Material | Extruded aluminium profile |
| ESD-suitable | Yes |
| Dry room (rF) | < 1 |
| Weight | 0.0099 kg |
| Scope of delivery | Height-adjustable bases, fastening material |
| Delivery condition | Not assembled |
| Required accessories | Foundation bracket, floor dowel |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3842996335 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
