The lift transverse unit HQ 2/G-H transfers workpiece pallets between longitudinal and transverse conveyor sections using four synchronized block cylinders. It handles total loads up to 240 kg, is ESD-safe with a duplex chain rated for EPA use, and mounts directly onto ST 2 or ST 2/H profiles (45 mm and 50 mm widths). Height-adjustable lateral guides serve as fixed stops or pallet change guides depending on installation.
Lift Transverse Unit HQ 2/G-H, max. 240 kg, ESD-Compatible, Duplex Chain - Bosch Rexroth 3842996370
BOSCH REXROTH Original product
Net price (excl. VAT)
€4,817.79
Item BRR-3842996370
Manufacturer no. 3842996370
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842996370
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842996370
Frequently Bought Together
The lift transverse unit HQ 2/G-H enables outfeeding and infeeding of workpiece pallets between longitudinal and transverse conveyor lines. Its compact design supports multi-level system layouts even where space is tight. Four synchronized block cylinders deliver a uniform, parallel lifting movement across the full load range.
- Handles total weights up to 2 kg/cm on the smallest pallet side and up to 240 kg overall
- Four synchronized block cylinders ensure uniform, parallel lift at all load levels
- Duplex chain conveyor medium - rated for EPA use, fully ESD-compatible
- Integrated chain tensioner with manual adjustment
- Height-adjustable strip-steel lateral guides usable as fixed stops or pallet change guides depending on installation
- Mounts onto ST 2/... sections (45 mm profile width) or ST 2/...-H sections (50 mm profile width)
- Compatible with WT 2, WT 2/E and WT 2/F workpiece pallets (PE wear pad required)
- Reversible operation supported; accumulation operation not permitted
- Cleanroom class ISO 7; suitable for dry rooms (RH <1 %)
- Supplied fully assembled; lateral guide kits included
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842996370 |
| Max. workpiece pallet total weight (mG) | 240 kg |
| ESD-compatible | Yes (chain suitable for EPA) |
| Cleanroom class | ISO Class 7 |
| Dry room (RH) | <1 % |
| Required compressed air connection (p) | 4 ... 6 bar |
| Pneumatic straight connection (dia.) | 8 mm |
| Track width, transverse conveyor (bQ) | 480 ... 1200 mm (preferred: 480, 640, 800, 1040, 1200) |
| Track width, longitudinal conveyor (bL) | 640 ... 1200 mm (preferred: 640, 800, 1040, 1200) |
| Nominal speed (vN) | 0, 6, 9, 12, 15, 18 m/min |
| Motor connection | S (cable/plug) or K (terminal box) |
| Motor mounting (MA) | R (right), L (left), M (centre) |
| Conveyor medium | Duplex chain |
| Compatible profile width | 45 mm (ST 2/...) or 50 mm (ST 2/...-H) |
| Delivery state | Fully assembled, incl. fastening material and lateral guide kits |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3842996370 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
