The CU 1/90 curve module redirects workpiece carriers through 90° without a dedicated curve drive - propulsion is provided by the adjacent belt section. Suitable for ESD environments (ISO Class 7 cleanroom), with accumulation capacity for up to 3 workpiece carriers and a maximum section load of 30 kg. Track widths of 80, 120 and 160 mm; lengths from 415 to 5,000 mm; curve direction left or right selectable.
Curve Module CU 1/90 for 90° Workpiece Carrier Transport, ESD-Suitable - Bosch Rexroth 3842998287
BOSCH REXROTH Original product
Net price (excl. VAT)
€2,975.30
Item BRR-3842998287
Manufacturer no. 3842998287
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998287
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842998287
Frequently Bought Together
- This Item: €2,975.30
- Transport Belt GT 1/A in PA 66, ESD-Safe, 1000 mm - Bosch Rexroth 3842992941-1000 €75.58
- Drive Module AS 1 for Transfer System TS 1, ESD-Compatible - Bosch Rexroth 3842999759 €1,875.07
Total price
The CU 1/90 curve module transfers workpiece carriers through a 90° change of direction in assembly and production lines. No independent drive is needed for the curve function - propulsion comes entirely from the connected belt section. The module is ESD-compatible (ISO Class 7) and rated for dry-room use (relative humidity below 1 %). Reversing operation is not possible; damping elements on workpiece carriers may only be fitted laterally and at the rear relative to the direction of transport.
- No additional curve drive required - propulsion via adjacent belt section
- ESD-suitable, ISO Class 7 cleanroom rated, dry room to r.H. <1 %
- Accumulation capacity up to 3 workpiece carriers, max. section load 30 kg
- Track widths 80, 120 and 160 mm; lengths 415 to 5,000 mm
- Curve direction right (KR=R) or left (KR=L); motor connection as cable/plug (AT=S) or terminal box (AT=K)
- Energy-efficient per Rexroth 4EE; supplied partially assembled
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842998287 |
| Curve angle | 90° |
| Track width b (direction of transport) | 80 / 120 / 160 mm |
| Length L (direction of transport) | 415 to 5,000 mm |
| Max. section load in accumulation mode | 30 kg |
| Accumulation capacity | max. 3 workpiece carriers |
| Nominal speed vN | 0 / 6 / 9 / 12 / 15 / 18 m/min |
| Curve direction | right (KR=R) or left (KR=L) |
| Motor connection | cable/plug (AT=S) or terminal box (AT=K) |
| ESD-suitable | yes |
| Cleanroom class | ISO Class 7 |
| Dry room | r.H. <1 % |
| Dimensions bWT x lWT / L / L1 / L2 | 80x80 mm: 415 / 144 / 318 mm | 120x120 mm: 455 / 184 / 358 mm | 160x160 mm: 495 / 224 / 396 mm |
| Scope of delivery | Belt section with third track, inner guide, outer guide, fastening material, connection kit (partially assembled) |
| Weight | 0.0099 kg (configurator base weight; final weight depends on configuration) |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3842998287 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
