Belt Section CSS/NT-3 with 3 Tracks for Glass Module Transport up to 160 °C - Bosch Rexroth 3842998633

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Belt Section CSS/NT-3 with 3 Tracks for Glass Module Transport up to 160 °C - Bosch Rexroth 3842998633

Bosch Rexroth ✓ Original product Brand new Made in Germany

Three-track longitudinal conveyor for safe transport of glass modules and plates at temperatures up to 160 °C, for example as a post-lamination transport system. The Viton-coated toothed belt delivers high friction to prevent module slippage and allows high acceleration and deceleration values. Track spacing (b1 to b4) is individually adjustable; suitable for cleanroom environments up to class 7 per ISO 14644-1.

Net
€3,709.88
excl. VAT
Item BRR-3842998633
Manufacturer no. 3842998633
Save Compare
Question about this item
Datasheet (PDF) 8 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The CSS/NT-3 belt section is a three-track longitudinal conveyor designed for the reliable transport of sensitive glass modules and plates at temperatures up to 160 °C. Adjustable track spacing (b1 to b4) ensures full-width support across the entire module. Gear motors are rated for frequency converter operation, enabling precise speed control.

  • Viton-coated special textile toothed belt with high friction coefficient - prevents module slippage even at high acceleration
  • Dynamic belt tensioner automatically compensates for temperature-induced belt elongation
  • Side-access belt replacement without realignment, including inner tracks via hexagonal shaft couplings
  • Reversible operation up to 1500 mm section length
  • Suitable for cleanroom use up to class 7 per ISO 14644-1
  • Standard lengths available from stock - reduced delivery times for replacement belts

Technical data

ParameterValue
Number of tracks3
Length min. (L min)550 mm
Length max. (l max)3000 mm
Track width b1 min / max180 / 1000 mm
Track width b2 min / max180 / 1000 mm
Track width b3 min / max180 / 1000 mm
Track width b4 min / max180 / 1000 mm
Overall width in transport direction (b min / max)255 / 2300 mm
Permissible load per trackmax. 0.3 kg/cm support surface length, max. 60 kg
Permissible load per belt sectionmax. 120 kg
Max. product temperature160 °C
Reversible operation up to section length1500 mm
Belt materialTextile toothed belt with Viton coating
Cleanroom classup to class 7 per ISO 14644-1
Motorordered separately
Length deviation0.5 mm; bxmin = 350 mm for motor mounting between tracks
Recommended accessoriesFrames SFS, Leg set SZS/N, Frequency converter FU, Toothed belt tensioner (tool)
Weightapprox. 0.01 kg (documentation weight; section weight on request)
ManufacturerBosch Rexroth
Manufacturer Nr.3842998633
HS-Code84313900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
ESD versionTEC
CertificationDIN EN ISO 14644-1

Downloads

Datasheet

Catalogue

Other

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
