Lift Transverse Unit LTS/B-3, 3-Track, Fully Assembled - Bosch Rexroth 3842998673
Datasheet (PDF)
The product may differ from the illustration
The LTS/B-3 lift transverse unit combines a belt section CSS/... with a lift unit to create right-angled branch sections in assembly conveyor systems. Designed for three tracks with individually adjustable track spacing (b1 to b3), it handles up to 60 kg per track and 120 kg per belt section. The unit is supplied fully assembled; gear motors and the required leg set SZS/B are ordered separately.

Lift Transverse Unit LTS/B-3, 3-Track, Fully Assembled - Bosch Rexroth 3842998673

BOSCH REXROTH Original product
Net price (excl. VAT)
€4,906.73
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842998673
Manufacturer no. 3842998673
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998673
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998673
Frequently Bought Together
Total price

The Bosch Rexroth lift transverse unit LTS/B-3 is a conveyor module for setting up right-angled section branches in transfer systems. It combines a belt section CSS/... with a two-position lift unit, and accommodates two to four tracks with individually configurable track spacing (b1 to b3) within the specified minimum dimensions.

  • Permissible load per track: max. 0.15 kg/cm support surface length, max. 60 kg (LTS/B)
  • Permissible load per belt section: max. 120 kg
  • O-rings for high friction coefficients and improved static friction during transverse conveying
  • Tracks without lateral guide; reversible across the entire value range
  • Simple toothed belt replacement
  • Gear motors suitable for frequency converter operation
  • Motor mounting on right (MA = R) or left (MA = L) per track (MS = 1 ... 4)
  • Motor connection with cable/plug (AT = S) or terminal box (AT = K)

Technical data

ParameterValue
TypeLTS/B-3
Tracks3
Lift positions2
Length [l]1864 ... 6000 mm (BG = 3); other sizes from 1264 mm
Track width b1 min / max240 / 600 mm
Track width b2 min / max216 / 600 mm
Track width in transport direction b min / max576 / 1320 mm
Max. load per track (LTS/B)60 kg
Max. load per belt section120 kg
DeliveryFully assembled; motors supplied separately
Required accessoryLeg set SZS/B
Weight0.0099 kg (shipping weight; system weight on request)
