Lift Transverse Unit LTS/F-2, Track Width 450-675 mm, 2-4 Tracks - Bosch Rexroth 3842998682
Datasheet (PDF)
The product may differ from the illustration
The LTS/F-2 lift transverse unit combines a CSS belt section with a lift unit to create right-angled branch points in assembly and conveyor lines. Two to four tracks with individually adjustable track spacing (b1 to b3) accommodate a wide range of line layouts. Permissible load reaches up to 0.15 kg/cm support surface per track and up to 120 kg per belt section.

Lift Transverse Unit LTS/F-2, Track Width 450-675 mm, 2-4 Tracks - Bosch Rexroth 3842998682

BOSCH REXROTH Original product
Net price (excl. VAT)
€4,102.32
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842998682
Manufacturer no. 3842998682
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998682
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998682
Frequently Bought Together
Total price

The LTS/F-2 lift transverse unit integrates a CSS belt section with a lift unit, enabling right-angled section branches within assembly and transport lines. The unit is delivered fully assembled; gear motors are supplied separately.

  • 2 to 4 tracks with individually determined track spacing (b1 to b3) - minimum dimensions must be observed
  • O-rings for high friction coefficients and improved static friction on the transverse conveyor
  • Tracks without lateral guide, reversible across the entire value range
  • Simple toothed belt exchange without special tooling
  • Motor mounting on right (MA = R) or left (MA = L) on each track of the belt section (MS = 1 to 4)
  • Motor connection via cable/plug (AT = S) or terminal box (AT = K)
  • Gear motors suitable for operation with frequency converter
  • Two lift positions

Technical data

SpecificationValue
AssemblyLift transverse unit LTS/F-2
Number of tracks2 to 4
Track width in direction of transport b min450 mm
Track width in direction of transport b max675 mm
Track width b1 min375 mm
Track width b1 max600 mm
Length l (BG = 1)1264 to 6000 mm
Length l (BG = 2)1564 to 6000 mm
Length l (BG = 3)1864 to 6000 mm
Length l (BG = 4)2230 to 6000 mm
Length l (BG = 5)2530 to 6000 mm
Permissible load per track (LTS/F)max. 0.15 kg/cm support surface, max. 40 kg
Permissible load per track (LTS/B)max. 0.15 kg/cm support surface, max. 60 kg
Permissible load per belt sectionmax. 120 kg
Lift positions2
DeliveryFully assembled, motors included separately
Required accessoriesLeg set SZS/B
More Information
Execution TEC
Manufacturer Nr. 3842998682
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.009900
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
