Linear slide carriage for the Bosch Rexroth EcoSlide system, designed for 90 mm wide profiles with slot 10. Handles compression loads to 5000 N and tensile loads to 2500 N at sliding speeds up to 12 m/min. An integrated spacer washer compensates manufacturing tolerances between carriage and profile.
EcoSlide Trolley 45x90x160 mm, Anodized Aluminium, 90 mm Profile Width - Bosch Rexroth 8981535326
BOSCH REXROTH Original product
Net price (excl. VAT)
€61.10
Item BRR-8981535326
Manufacturer no. 8981535326
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.8981535326
Country of originUnited States
Customs tariff number76169990
ConditionNew
Article
BRR-8981535326
Frequently Bought Together
- This Item: €61.10
- Roller Element RE 39, Black Plastic - Bosch Rexroth 3842520000 €7.90
- Idle Roller D32SK ESD, Green, PA - Bosch Rexroth 3842537962 €2.13
Total price
The EcoSlide trolley 45x90x160 is an anodized aluminium carriage for the Bosch Rexroth EcoSlide linear system. It mounts on profiles with 90 mm width (slot 10) and withstands compression forces up to 5000 N and tensile forces up to 2500 N. The integrated spacer washer offsets tolerances between carriage and profile; maximum sliding speed is 12 m/min.
- Compression load up to 5000 N, tensile load up to 2500 N
- Maximum torque around x axis: 100 Nm, around z axis: 200 Nm
- Sliding speed up to 12 m/min
- Spacer washer included for tolerance compensation between carriage and profile
- Material: aluminium, anodized, profile slot 10
- Machining note: to fit a clamping lever, the carriage bore must be drilled out to 9 mm
Technical data
| Parameter | Value |
|---|---|
| Dimensions | 45 x 90 x 160 mm |
| Profile slot | 10 |
| Profile width | 90 mm |
| Compression load Fmax | 5000 N |
| Tensile load Fmax | 2500 N |
| Torque around x axis Mmax | 100 Nm |
| Torque around z axis Mmax | 200 Nm |
| Max. sliding speed | 12 m/min |
| Material | Aluminium, anodized |
| Weight | 0.747 kg |
| Packaging unit | 1 |
| Recommended accessories | N10 flat slider, N10 flat lockable slider, spacer washer, clamping lever, N10 sliding block |
| Manufacturer Nr. | 8981535326 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | United States |
| Weight | 0.747000 |
| HS-Code | 76169990 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
